- 90+ modules and growing, including over 20 pre-built effects
- OLED screen for easy editing
- Store up to 64 patches in the onboard memory
- SD Card included for sample storage, patch transfers, and firmware updates
- ¼” Control Port accepts MIDI, expression pedal, control voltage, and external switch inputs
- ⅛” MIDI I/O ports accept ⅛”-to-MIDI adapters (included)
- 24-bit, 48kHz convertors with 32-bit internal processing
Modular Synthesis Meets Multi-Effects
The Empress ZOIA 10k blends modular synthesis with multi-effects, putting limitless sound design possibilities at your feet. With over 80 modules, including oscillators, filters, and LFOs, you can craft anything from classic delays and reverbs to complex synth patches—perfect for live performances or studio sessions.
Creative Freedom on Your Pedalboard
At the core of ZOIA’s design is an intuitive, customizable interface that invites musicians to explore and create unique sounds without ever needing a computer. With its illuminated grid and high-definition OLED screen, the ZOIA 10k makes it easy to see and shape every aspect of your patches in real time.
Exclusive Colourway
The ZOIA 10k limited edition celebrates ZOIA’s impact on sound design with a special beige finish and blue OLED screen, making it a must-have for collectors and ZOIA fans. This exclusive colourway is available only in 500 units worldwide.
Specifications
Input Impedance: >= 1MΩ
Output Impedance: 100Ω
Frequency Response (-3dB): 10Hz – 23.4kHz
Total Harmonic Distortion: 0.22%
Dynamic Range: 105.5 dBA
Input Headroom (no pad): +0.5 dBu
Input Headroom (6dB pad): +5.7 dBu
Input Headroom (12dB pad): +10.8 dBu
Output Headroom: +16.2dBu
Power Input Connector: 2.1mm Barrel Connector
Power Input Voltage: 9V DC (center negative)
Required Current: 300mA
Length: 5.7”
Width: 3.75”
Weight: 1.5lbs
